Get ready to experience your newest passion
QUICK Product Configurator
Lightest ebike kit, made easy and quick!
Select your power and battery. Once we'll receive your order, we'll contact you to sort out all the details, such as mount, bottom bracket, and other options.
Included Items in the motor kit:
- Lightest motor of your choice
- Integrated FOC sinewave controller, 30A phase continuous current, working up to 54V nominal, 63V max voltage.
- Ergal (Aluminum Alloy 7075 ) crankarms 165mm
- External premium freewheel
- Magnesium Chainring Spider
- Chainring of your choice
- 10T output sprocket
- Rear chain tensioner with pulley
- E-bike display
- Bluetooth APP for basic connection ( or advanced connection with Superhero Pack)
- Mounting brackets of your choice
- Speed sensor with magnet
- Wiring cable ( single connector for display in the basic configuration, multiple connector with Superhero Pack)
- Screws and spacers
- Bottom bracket
- User Guide download link
- Battery connector
Check all the pictures in the above gallery : in there you'll find the Option & Performance Chart and pictures.
QUICK Configuration Selection Guide
Motor Power:
Select the nominal power of your motor.
Not sure which one to choose? Send us some pictures by Whatsapp or by email : info@lightest.bike. Number: + 39 0376 390846Our system is open, so it works with third party batteries. However we suggest to use our batteries because those have been designed to deliver at least 25Amp continuously and 35Amp current burst. You can select here your battery. Please consider the following:
- 220Wh 36V : this battery only fits the 250W motor, and it's recommended if you are well trained and don't need much or prolonged support from the motor. As an indication, this type of battery can reduce your effort of 50% for a two-hour trip.
- 600Wh 48V: this battery is compatible with all the motor powers. It's recommended when you plan to use the motor for medium to long trips, with climbs around 1000-1500 meters of altitude.
- 670Wh 48V: this battery is compatible with all the motor powers. It's recommended when you plan to use the motor for medium to long trips, with climbs around 1100-1700 meters of altitude.
- 800Wh 48V: this battery is compatible with all the motor powers. It's recommended when you plan to use the motor for long trips, with climbs around 2000-2500 meters of altitude.
All the batteries have a lock, keys, battery mount, high current BMS and high current cable with connector. Also, all batteries come with the battery charger.
Battery charger
- 2A charger
allows you to fully charge your battery in the time below:
- 220Wh in 4hours
- 600Wh in 7 hours
- 670Wh in 8 hours
- 800Wh in 9 hours
- 7A charger
allows you to fully charge your battery in the time below:
- 220Wh NOT RECOMMENDED
- 600Wh NOT RECOMMENDED
- 670Wh NOT RECOMMENDED
- 800Wh in 3 hours
Please note that the images provided are solely indicative of the product and may not precisely reflect the final item. Variations in color, texture, or design may occur
